3M CBRN Gas Cartridge - 4/Box - FR-15-CBRN

This canister is designed for first responder applications commonly found in law enforcement, fire and emergency response (paramedics) environments. Unique, patented carbon technologies make this cartridge more comfortable for the wearer.

Approved to NIOSH Chemical Biological Radiological Nuclear (CBRN) requirements in conjunction with the following 3M™ Full Facepiece Respirators: FR-M40B-10, Small; FR-M40B-20, Medium; FR-M40B-30, Large and FR-7800B-S, FR-7800B-M and FR-7800B-L.

Designed for first responder applications commonly found in law enforcement
DIN cartridge connection type
4 canisters per case
3M™ FR-7800B Series and 3M™ FR-M40B Series

40mm NATO threaded design preferred by law enforcement

FR-15-CBRN Canister Specifications Can filter a wide range of chemical warfare agents such as:

Nerve agents: tabun (GA), sarin (GB), soman (GD), VX.
Mustard/Blister agents: H, HD, L.
Tear agents: CN, CS, CR, OC.
Blood agents: hydrogen cyanide (AC), cyanogen chloride (CK), arsine (SA).
Choking agents: chlorine, phosgene, chloropicrin (PS), and diphenylchloroarsine (DA).

Can also filter common industrial chemicals such as:

Organic vapors
Chlorine dioxide, chlorine, hydrogen fluoride, hydrogen sulfide and sulfur dioxide
Ammonia, methylamine
Formaldehyde
Nitrogen dioxide
Phosphine
Particles

Industrial Category:	Safety
Industrial Subcategory:	Respiratory
Industrial Subtype:	Gas Mask Canisters
Accessories:	No
Enhanced Comfort:	No
Enhanced Durability:	No
Eye Protection:	No
Harmonized Tariff Schedule Nbr:	8421990080
Maintenance Free:	No
Product Type:	Filter & Cartridge
Recommended Industry:	Military Tactical
Silicone Faceseal:	No
Six-point Head Harness:	No
Spare Parts:	No
Speaking Diaphragm:	No
UPC Code:	50051131529910
Manufactured By:	3M

Test Results for Canister FR-15-CBRN
Challenge Agent	Challenge Concentration (ppm)	Testing Relative Humidity (%)	Maximum Allowed Breakthrough (ppm)	Minimum Test Time (min)	TLV®1 / IDLH2 (ppm)	Maximum Use Concentration3 (ppm)
Ammonia (NH3)4	1000	50	50	> 25	25 / 500	500
Ammonia (NH3)5	2500	25 / 80	12.5	> 15	25 / 500	500
Chlorine Dioxide (ClO2)4	500	50	0.1	> 30	0.1 / 10	10
Carbon Tetrachloride (Organic Vapors)4	1000	50	5	> 25	5 / 300	250
Chlorine (Cl2)4	500	50	5	> 17.5	0.5 / 30	25
a-Chloroacetophenone (CN)4, 6	16	50	0.05	> 480	0.05 / 16	2.5
o-Chlorobenzylidenemalononitrile (CS)4, 6	3	50	0.05	> 480	0.05C7 / 0.25	0.25
Chloropicrin (PS)8	744	80	0.74	> 27	0.1 / 4.0	4
Cyanogen Chloride (CK)5	300	25 / 80	2	> 15	0.3C7 / ND (46.9)9	15
Cyanogen Chloride (CK)10	1591	80	3.2	> 30	0.3C7 / ND (46.9)9	15
Cyclohexane (Organic Vapors)5	2600	25 / 80	10	> 15	100 / 10000	5000
DMMP10, 11	591	Dry	0.008	> 59	NA	NA
Formaldehyde (CH2O)4	100	50	1	> 50	0.3C7 / 30	7.512
Formaldehyde (CH2O)5	500	25 / 80	1	> 15	0.3C7 / 30	7.512
Hydrogen Chloride (HCl)4	500	50	5	> 25	2C7 / 100	100
Hydrogen Cyanide (AC)13	3618	80	4.514	> 28	4.7C7 / 50.0	50
Hydrogen Cyanide (AC)5	940	25 / 80	4.715	> 15	4.7C7 / 50.0	50
Hydrogen Fluoride (HF)4	70	50	3	> 30	3C7 / 30	30
Hydrogen Sulfide, Escape (H2S)4	1000	50	10	> 30	10 / 300	300
Hydrogen Sulfide, Escape (H2S)5	1000	25 / 80	5	> 15	10 / 300	300
Methylamine (CH3NH2)4	1000	50	10	> 12.5	5 / 100	100
Nitrogen Dioxide (NO2)5	200	25 / 80	1 ppm NO2 or 25 ppm NO	> 15	3 / 50	50
Particulates (P100)4	200 mg total loading w/ 0.3µm MMAD DOP particles	NA	<0.03%	240016	10 mg/m3 I17 / ND 3 mg/m3 R18 / ND	500 mg/m3 150 mg/m3
Phosgene (CG)13	4943	50	2	> 25	0.1 / 2.0	2
Phosgene (CG)5	250	25 / 80	1.25	> 15	0.1 / 2.0	2
Phosphine (PH)4	1500	50	0.3	> 12	0.3 / 200	15
Phosphine (PH)5	300	25 / 80	0.3	> 15	0.3 / 200	15
Sulfur Dioxide (SO2)4	500	50	5	> 15	2 / 100	100
Sulfur Dioxide (SO2)5	1500	25 / 80	5	> 15	2 / 100	100
NA = Not applicable
ND = Not Determined
ppm = parts per million
mg/m3 = milligrams per cubic meter of air

3M CBRN Gas Cartridge - 4/Box - FR-15-CBRN

3M ID: 70071092970

UPC/GTIN: 50051131529910
