Lifa 40M Industrial Inspection Camera with Sony CCD and Waterproof Case

Industrial Video Inspection Camera, equipped with a Sony CCD Camera and a 40m cable reel, is designed for inspection of internal pipelines, drains and sewage systems. It's also suitable for inspection of air ducts, chimneys, machinery and building cavities.

All parts of this camera system (including camera head, LCD screen, cable reel, battery pack, etc) are mounted in a robust waterproof case and cables/wires are already plugged, which enables the camera to be a real OPEN & GO product.

High-Resolution Imaging: Featuring a 1/3 inch Sony CCD camera, our inspection camera provides crystal-clear images with a 120° wide view angle, allowing for comprehensive inspection of internal pipelines, drains, sewage systems, air ducts, chimneys, and more.
Extended Reach: Equipped with a robust 40-meter fiberglass rod cable neatly rolled into a stainless steel reel, the ProView 40M offers extensive reach without sacrificing maneuverability. The cable reel is fully rotatable within its case, ensuring hassle-free operation in tight spaces.
Durability and Protection: Each component, from the stainless steel camera head with IP68 waterproof level to the durable waterproof ABS suitcase, is designed to withstand harsh conditions. The camera's sapphire glass lens cover and 12 white LEDs enhance visibility in low-light conditions, making it an all-conditions tool.
Ease of Use: This OPEN & GO system features a convenient one-touch record/still image button and a 7-inch TFT/LCD monitor with DVR for instant playback and analysis. Set up is quick and intuitive, saving valuable time on the job.
Long-Lasting Battery Life: Powered by a rechargeable high-capacity 6600mA Li-battery, the camera system can operate continuously for up to 8 hours, ideal for extended inspection sessions.
Optional Upgrades: Enhance your diagnostic capabilities with optional features like the 512Hz Sonde, which helps locate the camera head from underground if displaced.

Camera Head
Center protector	Foam protector
Sensor:	1/3" Sony CCD
Cam head dimentions:	23mm (dia.) x 45mm (length)
Camera Material:	304# Stainless Steel
View Angle	120° wide angle
Lens Cover:	Sapphire Glass
Led lights:	12 High Bright White LEDs
Water proof:	IP68

Cable Reel
Material:	Fiberglass rod cable
Wheel:	Stainless steel wheel
Cable Length:	40m / 128ft
Connector:	Gold touch-point connector
Rotation:	Rotatable in the suitcase
Wheel Diameter:	33cm
Cable Diameter:	5.2mm

LCD Display and DVR
LCD Resolution:	800*480 pixels
Video Compress:	MPEG-4
Recording:	Video and audio recording
Picture:	Picture shot function
LCD Screen Size:	7 inch
Menu Language:	9 languages
Panel Control:	Any functions through buttons
External Memory:	SD Card (Max. 32GB)
