Husqvarna
Husqvarna PG 510 Floor Grinder - 220-240 V 1 ph 60 Hz - 970754903
- SKU:
- 406-HUSQ970754903
- UPC:
- 7333377596788
- MPN:
- 970754903
- Condition:
- New
- Availability:
- Call or Email for Availability!
- Shipping:
- Calculated at Checkout
Call or Email for Availability!
Frequently bought together:
Description
PG 510 Floor Grinder - 220-240 V 1 ph 60 Hz – 970754903
FLOOR GRINDER PG 510 | 220-240 V | 1 ph | 60 Hz | US
The PG 510 is a planetary floor grinder with three grinding discs and a total grinding width of 515 mm. It is suitable for removing coatings, grinding and polishing concrete, etc. The grinding head on the PG 510 is effectively sealed to keep dust and moisture out. This greatly extends the lifetime of the bearings and belts. The PG 510 is ideal as a rental machine and suitable for both professional and semi-professional work. Quick-release couplings allow the grinding head to be separated from the chassis which can then be easily folded for transport. The grinder also has a digital hour meter.
- Easy to use - The speed is fixed and no settings are required. The machine also has an user-friendly logical control panel with overload protection.
- Efficient dust management - Self-adjusting floating cover with brush list follows the surface and gives a tight seal to prevent the dust from entering the working environment.
- Easy to transport and set-up - The machine is light and fits easily in any car thanks to the compact design and foldable frame and dividable parts.
- Planetary operation - The machine has three grinding discs making it suitable for a wide range of applications.
- Sealed grinding head - The grinding head is effectively sealed to keep dust and moisture out. This greatly extends the lifetime of the bearings and belts.
- Time saving tool change - EZchange is an instant and hassle-free system for changing diamond tooling.
| Article ID | 970754903 |
| Category | Husqvarna/Floor Grinders/Planetary/Small Grinders |
| Article gross weight | 150000 g |
| Article gross weight (Calc) | 330.693 lbs |
| Direction of rotation | One direction |
| Engine Power (As rated by the engine manufacturer) (HP) | 4 hp |
| Engine Power (As rated by the engine manufacturer) (kW) | 3 kW |
| Frequency | 60 Hz |
| Grinding disc diameter (mm) | 230 mm |
| Grinding disc diameter (in) | 9 in |
| Grinding disc speed - Min | 0 rpm |
| Grinding disc speed - Max | 438 rpm |
| Grinding pressure - max | 80 kg |
| Grinding width (in) | 20 in |
| Grinding width (mm) | 515 mm |
| Number of grinding discs | 3 |
| Packaging height (mm) | 1050 mm |
| Packaging height (In) | 41.339 in |
| Packaging length (mm) | 1020 mm |
| Packaging length (in) | 40.157 in |
| Packaging width (mm) | 610 mm |
| Packaging width (in) | 24.016 in |
| Phases | 1 ph |
| Pins | 2 |
| Power source | Corded |
| Product size height (in) | 37 in |
| Product size height (mm) | 950 mm |
| Product size length (in) | 60 in |
| Product size length (mm) | 1525 mm |
| Product size width (mm) | 555 mm |
| Product size width (in) | 22 in |
| Rated current | 18 A |
| Voltage | 220-240 V |
| Weight (complete product w/o side packed articles) | 133 kg |
