Husqvarna
Husqvarna Wall Saw WS 8 | Standard - 967971301
- SKU:
- 406-HUSQ967971301
- UPC:
- 7392930269392
- MPN:
- 967971301
- Condition:
- New
- Availability:
- Call or Email for Availability!
- Shipping:
- Calculated at Checkout
Call or Email for Availability!
Frequently bought together:
Description
Wall Saw WS 8 | Standard – 967971301
WALL SAW WS 8 | STD
The WS 8 is a streamlined electric wall sawing system featuring next-generation PRIME technology. With a cutting depth capacity of up to 395 mm and an impressive power-to-weight ratio, the light and effective WS 8 is particularly tailored to smaller or mid-sized projects. The system is operable with both 3-phase and 1-phase power sources. A user-friendly design and modularity make the WS 8 a top choice for all-round cutting tasks.
- X-Halt – blade brake operation with PRIME - Connecting your PRIME product to a PP 8 or PP 70 gives you access to the X-Halt blade brake function, capable of stopping the rotation of the blade in a fraction of a second.
- Explore the modular power of PRIME - PRIME stands for Powerful, Revolutionary, Intelligent, Modular and Electric. Which means great cutting, sawing and drilling power in a compact, sturdy and flexible package. If you need high-performance electric equipment that can handle most jobs, PRIME is for you.
- Easy to transport and setup - Built on a modular system, the saws are easy to carry thanks to the optimized weight of each module. The weight is also evenly distributed between rail and saw head, because the carriage stays on the track.
- Efficient and fast sawing - Blade motor and both feeding motors can be operated individually at the same time with maximum power.
- Efficient and flexible - With mechanic parallel movement the attachment stays horizontal. The chain works in two directions.
- Quick and easy change of blade direction - With the wireless remote control it's easy to change the blade rotation to get the water spray in the desired direction.
- Sawing on both sides of the track - Versatile and efficient setup with symmetric track and carriage.
- Straight cuts with minimal wear - Small distance between track and blade gives a straight cut, generating minimal wear on both saw and blade.
- Durable and light blade guard - Made of aluminum, extremely durable, light and easy to install.
- Optimized speed for each cutting application - The spindle has variable rpm control which allows you to find the ideal speed for each blade dimension, blade type and cutting material.
| Article ID | 967971301 |
| Category | Husqvarna/Wall Saws/Tools/ |
| Article gross weight | 124000 g |
| Article gross weight (Calc) | 273.373 lbs |
| Blade diameter - Min (mm) | 600 mm |
| Blade diameter - Min (in) | 24 in |
| Blade diameter - Max (mm) | 900 mm |
| Blade diameter - Max (in) | 36 in |
| Cutting depth - Max (mm) | 395 mm |
| Cutting depth - Max (in) | 15.55 in |
| Max spindle torque | 68 Nm |
| Number of gearbox speeds | 1 |
| Output shaft RPM - max | 1150 rpm |
| Packaging height (mm) | 1470 mm |
| Packaging height (In) | 57.874 in |
| Packaging length (mm) | 1200 mm |
| Packaging length (in) | 47.244 in |
| Packaging width (mm) | 800 mm |
| Packaging width (in) | 31.496 in |
| Power source | Corded |
| Product size height (in) | 16.22 in |
| Product size height (mm) | 412 mm |
| Product size length (in) | 11.26 in |
| Product size length (mm) | 286 mm |
| Product size width (mm) | 350 mm |
| Product size width (in) | 13.78 in |
| Sound power level - guaranteed (LWA) | 105 dB(A) |
| Sound power level - measured | 119 dB(A) |
| Sound pressure level at operators ear (LpA) | 105 dB(A) |
| Spindle starting torque | 48 Nm |
| Water flow - min | 0.92 gal (US)/min |
| Water flow - min | 3.5 l/min |
| Water pressure - max (bar) | 8 bar |
| Water pressure - max (psi) | 116 psi |
| Water temp at Min flow - max | 35 °C |
| Weight | 203 lbs |
| Weight (complete product w/o side packed articles) | 92 kg |
| Weight saw unit (lbs) | 41 lbs |
| Weight saw unit (kg) | 19 kg |
