Husqvarna Wet/Dry Drill Motor DM 220 100-120 V - 1-Ph 60 Hz 1 1/4" - 966563503
Couldn't load pickup availability
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Wet/Dry Drill Motor DM 220 100-120 V - 1-Ph 60 Hz 1 1/4" - 966563503
DRILL MOTOR DM 220 100-120 V | 1-ph | 60 Hz | US | 1 1/4"
Handheld electric core drill for both dry and wet drilling. DM 220 has a level guiding system with a LED indicator, making it a perfect choice when looking for a drill motor with precision and efficiency. The ergonomically designed handle with D-handle gives you good control while drilling. Handheld core drilling up to 4 in. or drilling with stand up to 6 in. Suitable for light applications such as ventilation, plumbing pipes, electrical sockets and cables. An excellent choice for professionals as well as less experienced users.
- 360 ° adjustable front handle - For best ergonomic position
- Guidance for exact drilling - An electronic positioning system shows when the machine is in a vertical, horizontal or preferred angled position.
- Overload protection - The machine uses pulsation to warn you of an approaching overload. If the load is not reduced the motor will shut off, to prevent overheating. Elgard increases productivity and extends product life.
- Durable and ergonomic design - Durable and shock-proof, designed to protect the electronics. Easy to carry and install thanks to low weight and ergonomic design.
- Dry and wet drilling - Easy to switch between dry and wet drilling
- Smooth start with normal fuses - Softstart lowers incoming current to reduce amperage when starting the motor.
- Elgard - The machine uses pulsation to warn you of an approaching overload. This increases productivity and extends product life.
- Electronic positioning system - Shows when the machine is in a vertical, horizontal or preferred angled position. This provides efficient drilling.
- Smart Start ® - Used with starting a hole, speed is reduced by half using the Smart Start ® button, which reduces vibration.
- Softstart - An electronic current limiter for soft starts with normal fuses. This gives you a smooth start with high productivity and reduces initial load on motor.
- Angle drilling - Drilling holes in stepless adjustable angles.
- Horizontal drilling - Drilling horizontally.
- Vertical drilling - Drilling upwards and downwards.
- Channels, pipes and cables - Drilling ventilation channels and holes for pipes and cables.
| Article ID | 966563503 |
| Category | Husqvarna/Concrete Core Drills/Handheld Core Drills/ |
| Article gross weight | 14200 g |
| Article gross weight (Calc) | 31.306 lbs |
| Coolant | Wet /dry |
| Drill bit diameter handheld - Max (in) | 4 in |
| Drill bit diameter handheld - Max (mm) | 100 mm |
| Drill bit diameter with stand - Max (mm) | 150 mm |
| Drill bit diameter with stand - Max (in) | 6 in |
| Frequency | 60 Hz |
| Number of gearbox speeds | 3 |
| Packaging height (mm) | 150 mm |
| Packaging height (In) | 5.906 in |
| Packaging length (mm) | 660 mm |
| Packaging length (in) | 25.984 in |
| Packaging width (mm) | 520 mm |
| Packaging width (in) | 20.472 in |
| Phases | 1 ph |
| Power source | Corded |
| Product size height (in) | 15 in |
| Product size height (mm) | 376 mm |
| Product size length (in) | 22.4 in |
| Product size length (mm) | 560 mm |
| Product size width (mm) | 105 mm |
| Product size width (in) | 4.2 in |
| Rated input power (kW) | 1.85 kW |
| Rated input power (hp) | 2.5 hp |
| Recommended drill bit diameter - min | 1 in |
| Recommended drill bit diameter - min | 25 mm |
| Sound power level - guaranteed (LWA) | 108 dB(A) |
| Sound power level - measured | 107 dB(A) |
| Sound pressure level at operators ear (LpA) | 93 dB(A) |
| Spindle speed unloaded gear 1 | 730 rpm |
| Spindle speed unloaded gear 2 | 1700 rpm |
| Spindle speed unloaded gear 3 | 3600 rpm |
| Spindle thread - inner | 5/8" 11 UNC |
| Spindle thread - outer | 1 1/4" 7 UNC |
| Voltage | 100-120 V |
| Water connector | G 1 / 4" |
| Water pressure - max (bar) | 8 bar |
| Water pressure - max (psi) | 116 psi |
| Weight | 16.5 lbs |
| Weight (complete product w/o side packed articles) | 7.5 kg |
MFG Part #: 966563503
UPC #: 7391883548660
| Product Type | Husqvarna Parts & Accessories |
|---|
